Jacobsen Eclipse 360 ELiTE – the latest generation of the proven Samsung SDI ELiTE lithium battery
- Combines several years of experience in one machine
- More than 22 golf greens per charge
- No hydraulic oil
- Swing-out centre unit
Overview
5-YEAR WARRANTY
YOUR UNIQUE OPPORTUNITY FOR ORDERS PLACED BY 31.12.2024
Get ready for the future with our all-inclusive care package – designed specifically for the Jacobsen Eclipse® 360 ELiTE. As one of the first to choose the Eclipse® 360 ELiTE mower, you'll receive not only a revolutionary product but also an exclusive 5-year warranty. Trust in state-of-the-art technology and enjoy comprehensive protection for years to come. Secure your advantage now!
The new Eclipse 360 ELiTE fully electric greens mower with the latest Samsung SDI lithium battery can do more than just cut grass. Operating costs, noise emissions and maintenance downtime are significantly reduced. A mower with the most advanced precision technology and the best cut in the world, Jake's trusted signature cut.
The latest ELiTE lithium-ion battery and a hydraulics-free design make the fully electric Eclipse 360 ELiTE the most environmentally friendly, quietest and most advanced mower for your golf course or sports turf.
- Cutting width 1.60 m
- Battery pack 260 Ah lithium
- Cutting cylinders 7, 9, 11 or 15
- Height of cut 1.6 mm – 11.1 mm
- No hydraulics
- Mows more than 22 golf greens on a single charge.
Our field sales team will be happy to answer your questions and looks forward to arranging an appointment with you:
YOUR CONTACTS FOR GERMANY
Technical data
| Cylinder & blades | |
|---|---|
| Number and size | Three 22″ x 5″ cylinders |
| Cutting width | 1.60 m |
| Material | Hardened manganese carbon steel |
| Lift | New durable linear actuators |
| Cutting frequency | 0.91 mm – 6.35 mm with 15-blade units, electronically adjustable |
| Traction, brakes & speed | |
| Traction | Optional 3WD – PM; 3.2 hp (2.4 kW); 2WD – AC; 4.4 hp (3.3 kW) |
| Cylinder drive | One brushless motor per unit, 1.3 hp (0.97 kW) |
| Hydraulic system | no hydraulic oil |
| Service brake | Dynamic, regenerative braking system |
| Parking brake | Automatic, electromagnetic multi-plate |
| Steering | Drive-by-wire steering with feedback control |
| Mowing speed | 0 – 8.9 km/h; electronically adjustable top speed |
| Transport speed | 0 – 14.5 km/h; electronically adjustable top speed |
| Weights & dimensions | |
| Weight | 725 kg with groomer, rear roller brushes, grass catchers and 15-blade units, charger and aluminium front rollers |
| Length | 2.56 m with grass catchers |
| Height | 2.01 m with ROPS |
| Wheelbase | 1.32 m |
| Transport width | 1.72 m |
